Description
Compact CQB style sight with 85mm eye relief and wide field of view. A compact sight with the sharpest image and improved light transmission. Bright picture for using from dawn to dusk.
Prismatic design allows us to make much more compact and lightweight scopes with superior optical performance. Being compact allows for much better Gun/Scope weight distribution, the weight being further back massively reduces fatigue, which allows the shooter to stay out longer and shoot more accurately.
Supplied with MOA adjustable set of mounts.
| Parameter | Value |
|---|---|
| Magnification, X | 5 |
| Objective Lens Diameter, mm | 30 |
| Eye Relief, inches / mm | 3.35 / 85 |
| Tube size, mm | 34 |
| Field of View, ft@100yds/ m@100m | 33 / 10.2 |
| Minimum Focusing, m | 6 |
| Diopter adjustment, dpt | 3 +/- |
| C lick Value (MIL /MOA/cm@100m) | 0.1 / 0.338 / 1 |
| C licks per Revolution | 50 |
| Travel Per Rotation (MIL / MOA) | 5 / 15 |
| Max Elevation Adjustment (MIL / MOA) | 28 / 83 |
| Max Windage Adjustment (MIL / MOA) | 28 / 83 |
| Weight (without mounts) oz / gr | 17.14 / 486 |
| Weight (with MOA adj. mounts) oz / gr | 22 / 624 |
| Waterproof and Nitrogen filled | YES |
| Shock Proof (up to 600G) | YES |
