5×24 Prismatic Scope

The lightest and most compact model in our 5x series, compact CQB-style sight with 45mm eye relief

Original price was: €266,95.Current price is: €234,00.

Description

The prism-based optical system of the 5×24 prismatic scope significantly reduces its size compared to traditional day scopes by eliminating the large objective lens, bulky housing, and long eye relief, without compromising light transmission, magnification, or field of view.

Its expansive field of view is at least twice as wide as that of traditional scopes, allowing for faster target acquisition and improved situational awareness.

Fitted with Extra-Low Dispersion (ED) glass, this riflescope delivers natural colour reproduction with minimal chromatic aberration, resulting in exceptional clarity and a crystal-clear image, even at extreme distances.

The prismatic design enables a far more compact and lightweight scope while delivering superior optical performance. Its compact form also improves rifle and scope weight distribution, with the weight positioned further back to significantly reduce fatigue. This allows the shooter to remain comfortable for longer and maintain greater accuracy over extended periods.

All Immersive Optics riflescopes are CNC machined for precision and reliability, featuring nitrogen-filled optical channels for anti-fog performance and a waterproof sealed design for protection against moisture. An innovative lens cap retention system allows the caps to be securely clipped to the side of the riflescope, eliminating distractions while shooting.

Depending on the model selected, the 5×24 prismatic riflescope is available with either a glass-etched illuminated Mildot or Mildot Extended reticle, alongside high-precision windage and elevation controls, and is supplied with a set of MOA adjustable mounts.

ParameterValue
Magnification, X5
Objective Lens Diameter, mm24
Eye Relief, inches / mm1.77 / 45
Tube size, mm30
Field of View, ft@100yds/ m@100m34 / 11.4
Minimum Focusing, m6
C lick Value (MIL /MOA/cm@100m)0.1 / 0.338 / 1
C licks per Revolution50
Travel Per Rotation (MIL / MOA)5 / 15
Max Elevation Adjustment (MIL / MOA)28 / 83
Max Windage Adjustment (MIL / MOA)28 / 83
Sight dimensions, mm72 x 53 x 130
Sight dimensions, in2,8 x 2,1 x 5,1
Weight (without mounts) oz / gr10.7 / 304
Weight (with MOA adj. mounts) oz / gr15.3 / 434
Waterproof and Nitrogen filledYES
Shock Proof (up to 600G)YES

Additional information

Weight1 kg
Dimensions17 × 15 × 10 cm
Reticle

MILDOT, MILDOT RAPID
